Parameters | Unit | Specifications | |||
---|---|---|---|---|---|
2*1*8 | 4*1*4 | 4*4*4 | |||
Insertion Loss | Max | dB | 10.1 | 7.0 | 8.5 |
Polarization Dependent Loss | Max | dB | 0.3 | 0.3 | 0.4 |
Return Loss | Min | dB | 55 | ||
Directivity | Min | dB | 55 | ||
Operating Temperature | ℃ | -40 ~ 85 | |||
Storage Temperature | ℃ | -40 ~ 85 | |||
Operating Humidity | Max | 95% RH | |||
Storage Humidity | Max | 95% RH |
Parameters | Unit | Specifications | |||
---|---|---|---|---|---|
2*1*8 | 4*1*4 | 4*4*4 | |||
SUS Case Dimension | Width | nm | 7(±0.5) | ||
Height | nm | 4(±0.5) | |||
Length | nm | 55(±0.5) | |||
Input Fiber Type | - | 4ch Ribbon | 8ch Ribbon | ||
Output Fiber Type | - | 8ch Ribbon(ISO Color) | |||
Input / Output Length | mm | 1,000(±50) | |||
Connector Type | - | None |
